Process cooling water (PCW) 46 Series spools with integrated 46A Series Three Piece Ball Valves: Pipe x 150# ANSI Flange with Blind. (See drawings for example configurations-we can build to your required dimensions).

Stainless Steel 304 / 316, seats / seals: PTFE / Teflon

Valve / Branch: Size Range 1/2", 3/4" 1", 1-1/2", 2", 3", 4"

Main run: Size Range 1", 1-1/2", 2", 3", 4", 6", 8".

Pressure Rating: 1000psi (69 bar) 1/2"- 4".

Cv Value per size: 1/2" 19, 3/4" 35, 1" 50, 1-1/2" 200 2" 350, 3" 1100, 4" 2100
